1-Wire Interfaces

DS9097U-009#

1-Wire COM Port Adapter with ID-Chip

• True-Ground Interface to an RS232 COM Port for Reading and Writing 1-Wire Devices
• Works with Bipolar as well as Unipolar Logic Signals
• Compatible to COM port of (±)5V to (±)12V

DS9097U-E25#

1-Wire COM Port Adapter DB-25

• True-Ground Interface to an RS232 COM Port for Reading and Writing 1-Wire Devices
• Works with Bipolar as well as Unipolar Logic Signals
• Compatible to COM port of (±)6V to (±)12V

DS9097U-S09#

1-Wire COM Port Adapter

• True-Ground Interface to an RS232 COM Port for Reading and Writing 1-Wire Devices
• Works with Bipolar as well as Unipolar Logic Signals
• Compatible to COM port of (±)5V to (±)12V

DS9490B#

USB to iButton Adapter

• High-Speed 12Mbps Universal Serial Bus (USB) Interface
• Supports Standard and Overdrive 1-Wire® Communication
• Slew-Rate-Controlled 1-Wire Timing and Active Pullup for Improved 1-Wire Network Performance

DS9490R#

USB to 1-Wire Adapter

• High-Speed 12Mbps Universal Serial Bus (USB) Interface
• Supports Standard and Overdrive 1-Wire® Communication
• Slew-Rate-Controlled 1-Wire Timing and Active Pullup for Improved 1-Wire Network Performance

Link45

Advanced 1-Wire COM Port Adapter

• Advanced 1-Wire front end based on extensive research
• Slew controlled drivers reduce EMI and ringing
• Consistent 1-Wire waveform timing

Link45i

Advanced 1-Wire COM Port Adapter with ID-Chip

• Advanced 1-Wire front end based on extensive research
• Slew controlled drivers reduce EMI and ringing
• Consistent 1-Wire waveform timing

LinkHubE

1-Wire Ethernet Hub, 32K

LinkHubS

1-Wire Serial Hub, 32K

LinkOEM

1-Wire Adapter Module card

LinkTH

ASCII Sensor Reader

LinkUSB-M

Advanced 1-Wire USB Adapter

• Advanced 1-Wire front end based on extensive research
• Slew controlled drivers reduce EMI and ringing
• Consistent 1-Wire waveform timing

LinkUSB-T

Advanced 1-Wire USB Adapter with Screw Terminal

• Advanced 1-Wire front end based on extensive research
• 3-pin screw terminal provides output to the 1-Wire bus
• Slew controlled drivers reduce EMI and ringing

LinkUSBi-M

Advanced 1-Wire USB Adapter with ID

• Advanced 1-Wire front end based on extensive research
• Slew controlled drivers reduce EMI and ringing
• Consistent 1-Wire waveform timing

LinkUSBi-TH

Advanced iButton USB Adapter with ID

• Advanced 1-Wire front end based on extensive research
• All-in-one iButton read head built into the body of the device
• Slew controlled drivers reduce EMI and ringing

COM to 1-Wire USB Adapter

USB to 1-Wire Adapter

OW-SERVER-ENET

1-Wire to Ethernet Server (Rev. 2)

• Real-Time Graphing and Logging through Web Browsers.
• Reads all active devices every 2 seconds
• Firmware can be flash upgraded from remote
